LIFEPO4

The STF Lithium Iron Phosphate (LiFePO4) rechargable cells are one of the most powerful and most stable cells available along with an amazing life cycle of more than 3000 cycles. The High Quality LiFePO4 is a 6000 mah cell with a 1C(6A) continuous discharge and 3c(18A) peak discharge. These cells can work in high temperature environments which might not be favourable for the Li-ion or Li-po cells.  The cell is availaible in the 32650 / 32700 size which means that the diameter of the cell is 32mm and height is 70 mm which is quite compact for the power it gives. With a life cycle of more than 3000 cycles with good performance, this is a fit and forget solution for your battery packs in Electric Vehicles, Solar panels. Inverters, Warehouse Robots and all other high power applications which require longer life cycles.

The LiFePO4 chemistry has been around for some time but has caught up for the commercial markets due to innovation in the anode material and due to hits high stability in high stress environments and its ability to provide continued high performance. These cells are being used by most leading Electric Vehicle Battery Pack users who are looking for higher

performance and increased lifespan of the battery pack.

The benefits of the LiFePO4 cells over Li-ion and Lead acid batteries  are :

LiFePO4 cells are much more stable chemically and non combustible. At high temperatures or if the battery is mishandled the phosphate based cathode material will not burn. Hence LiFePO4 are much more safe for E-Vehicles and mobile robots

LiFePO4 cells offer much longer lifetime as compared to a Lead Acid or a Li-ion cell. The LiFeP04 provides more than 3000 cycles under proper handling and upto 70% DOD( Depth of Discharge). Also the shelf life of the cell is much longer with a lower self-discharge rate.

The LiFePO4 cells offer higher performance compared to a normal 1C Li-ion 18650 cell. The commonly availaible Li-ion cell are rated for 2 A discharge rate whereas the LiFePO4 1C cell provides a 6A discharge rate. There is also very little voltage drop during discharge which is much higher in a lead acid battery.

The LiFePO4 is a nontoxic material, non-contaminating material which contains no rare-earth minerals. This makes it a much more environment friendly choice compared to the lead acid and Lithium batteries.

Cell Specification

  • 3.2V 32650 / 32700 6000mAh LiFePO4 battery
  • Nominal Voltage:3.2V
  • Norminal Capacity(0.2C): 6000mAh
  • Charging Cut-off voltage:3.7V
  • Discharging Cut-off voltage:2.5V
  • Max.Charging Current(Continue):1C
  • Max.Discharging Current(Instantaneous):3C
  • Cell’s Diameter:32mm
  • Cell’s Height:70mm
  • Cell’s Weight:145g
  • Charging Methods Standard: 0.2C*6.5Hrs
  • Operating Temp Charge: 0ºC~45ºC
  • Discharge: 0ºC~45ºC
  • Storage: -20ºC~60ºC

Battery Specification 12.8V Pack

ITEM

Unit

SPECIFICATION

Technology

V

LIFEPO4

Nominal Voltage

V

12.8V

Typical Capacity

Ah

24AH

No of Cell

No.s

16

Dimension

mm

160mm X 250mm X 100mm (approx)

Individual Cell Capacity

V, mAH

3.2V,6000mAh

Cell Configuration



4S4P(4 in series,4 in parallel)

Battery Management Circuit functions



Over Voltage Protection, Under Voltage Protection, Cell Balancing

Upper cutoff voltage (Full charge Voltage)



V



13.9V

Lower cutoff voltage (Charge end Voltage)

V

10.5V Nearly

Maximum Charge Current



Amps



10 Amps

Charge Voltage

V

14.6V

Maximum Continuous

Discharge Current



Amp



20Amps



Operating Temperature



°C

Charge:    0°C to 50°C Discharge: 0°C to 55°C



Storage Temperature



°C

1month: -20°C to 45°C 3months -20°C to 35°C

  Notes:-

          We have all type of Li-Ion Batteries in any voltage and capacity and standards based on client requirement we manufacture and handover. The two model mentioned above are the most efficient batteries for EV.
